Tester for Electrolytic Capacitor Leakage Current AC/DC 0-200V/0-500V 10nA-19.9mA LED Measuring Instrument (AU)

LW-2686 AC/DC Electrolytic Capacitor Leakage Current Tester 0-200V/0-500V 10nA-19.99mA LED Measuring Instrument Features: 1. Intelligent automatic conversion, controlled by microprocessor for charging tests 2. 3 bit voltage, current 31/2 bit dual digital display. 3. The minimum current resolution reaches 1nA, and the reset button automatically erases the base number. 4. Test the current value lock function, with strong anti-interference ability. 5. Measuring voltage: 0-200V, 0-500V adjustable on two levels, with an accuracy of 1%+2 words 6. Leakage current test range: three-and-a-half digit display, 10nA-19.99mA, 2% accuracy+2 words, maximum resolution: 1nA 7. Maximum charging current: 200mA 10% 8. Charging time: set by selector, range: 0-99.9S Accuracy: 2%T set 0.5S 9. Leakage current preset: selector setting, range: 0-99 * 10n (nA) 10. Control method: microprocessor 11. Automatically free base 12. Charging/measuring can be automatically or manually converted to "charge/measure/discharge" 13. Supply voltage: AC200V 5% 14. Power frequency: 50Hz 5% 15. Power consumption: 30 W. 16. Limit size: 350 x 355 x 130 (mm) 17. Weight: approx. 6 kg

• - Test the leakage current of AC/DC electrolytic capacitors
• - Wide voltage range: 0-200V/0-500V
• - High sensitivity: 10nA-19.9mA
• - LED display for easy reading
• - Suitable for various applications
